17 4PH Stainless Steel Suppliers
17-4PH (also known as Alloy 17-4) is a high-strength, stainless steel made up of chromium, nickel, copper and niobium. With precipitation-hardening and martensitic qualities, alloy 17-4 is both tough and corrosion-resistant. 17-4PH maintains high tensile strength and hardness, up to 316°C, and excellent oxidation resistance up to 593°C. Alloy 17-4 also has good creep-stress rupture properties up to 482°C.
Speak to China Alloy Parts today if you would like to place an order for 17-4PH material - we can supply in many forms, including plate, round bar and sheet. To get in touch, please call us, or leave us a message using the contact form below.
17-4PH Stockist Range
| Product Form | Range From | Range To | |
|---|---|---|---|
 |
17-4PH Plate |
6.35mm | 76.2mm |
 |
17/4PH Round Bar |
6.35mm | 640mm |
 |
17/4PH Square Bar |
70x70mm | |
 |
17/4PH Flat Bar |
180x70mm | |
 |
17/4PH Sheet |
4.0mm |
Get In Touch
Beneficial Properties
- Flexibility Good workability, weldability and easy to machine
- Corrosion-Resistant High resistance to certain corrosive environments and elements, fatigue and wear
- Durability Strong performance, toughness and resilience
- Magnetic Permeability A high measure of magnetic permeability
Markets & Applications
- Aerospace manufacture (undercarriage components, fasteners, rocket fittings
- Paper mill equipment
- Nuclear waste casks and production
- Mechanical components such as: springs, screws, bolts, gears
- Chemical processing plants and oil and gas production
- Offshore and marine mechanical components
- Helicopter deck platforms and foils
17-4PH Composition
Mechanical Properties
| Yield Strength | KSI (MPa) | ≥ 105 (725) |
| Tensile Strength | KSI (MPa) | ≥ 124 (860) |
| Hardness | HB | ≥255 |
| Elongation | % | ≥16 |
| Impact Charpy-V -46°C | J | ≥41 |
Technical Specifications
| ASTM | UNS | Werkstoff | AISI | |
| A564 | S17400 | 1.4542 | 630 Type 630 |
Chemistry
| Nickel | Ni | 3.0-5.0 |
| Iron | Fe | Balance |
| Carbon | C | 0.7 Max |
| Silicon | Si | 1.0 Max |
| Manganese | Mn | 1.00 Max |
| Sulphur | S | 0.030 Max |
| Phosphorus | P | 0.040 Max |
| Chromium | Cr | 15.00-17.50 Max |
| Copper | Cu | 3.0-5.0 |
| Niobium | Nb | 0.15-0.45 |
Physical Properties
| Density | g/cm^3 | 7.82 |
| Melting Point | °F | 2560-2625 |
| °C | 1404-1440 | |
| Modulus of Elasticity at 20°C | MPa | 196000 |
| Thermal Conductivity at 20°C | W/m.K | 18.4 |
| Thermal Expansion | x10-6/K | 10.8 |
| Electrical Resistivity | 10-6Ω.m | 0.08 |
| Poisson’s ratio | 0.272 |
Contact us about Alloy 17-4 using the details below
Whether you’re looking for a bulk order of 17 4 PH stainless steel plate, or you need advice on which 17 4PH material would be right for your application, speak to China Alloy Parts Ltd.
We offer a bespoke service so, if you don’t see the size or form that you require, contact us either by phone, email or our contact form below, and we will provide a solution to your requirements.
